Application of Arc Flash Protective Clothing in Automation Equipment Commissioning: PLC, Distribution Cabinet, and Control Panel Operations



With the widespread adoption of industrial automation, PLC control systems, distribution cabinets, and electrical control panels have become core components of production lines, smart factories, and robotic systems. However, during commissioning, maintenance, and troubleshooting, engineers often need to work in energized or near-energized environments. A short circuit caused by a loose connector, accidental tool contact, or misoperation can instantly trigger an arc flash event.

In such precise yet high-energy work conditions, arc flash protective clothing is not just “workwear” — it is the last line of defense for engineers’ lives.


1. Arc Flash Hazards in Automation Commissioning

Task Type Risk Scenario Potential Consequence
PLC wiring / editing programs near terminals Loose screws or contact tools cause a short circuit Arc flash with intense heat and sparks
Energized testing inside distribution cabinet Fault in contactor or breaker during switching Instantaneous arc blast
Control panel maintenance Aged insulation or dust buildup causes discharge Molten metal splashes burn hands or face
Voltage/current measurement under load Test probes slip accidentally Explosive arc discharge

2. How Arc Flash Clothing Protects Commissioning Engineers

  • Heat and Flame Resistance – Prevents fabric from melting and sticking to the skin during an arc flash.

  • Molten Metal Protection – Blocks hot particles ejected from breakers or contactors.

  • Shockwave Mitigation – Multilayer structure helps absorb part of the blast pressure.

  • Integrated PPE System:

    • Arc-rated gloves → Prevent electric shock and burns to the hands

    • Face shield / visor → Protects against arc light and flying debris

    • Insulated footwear → Prevents step voltage hazards


3. Recommended Arc Rating for Automation Commissioning

Task Scenario Recommended ATPV/EBT Rating Suggested PPE Setup
PLC programming / control panel inspection 8–12 cal/cm² Long-sleeve arc-rated clothing + gloves + face shield
Energized switching / cabinet adjustment 12–25 cal/cm² Enhanced arc suit + hood + insulated shoes
Fault diagnostics / high spark environment ≥25 cal/cm² Full arc flash suit + full-coverage hood

4. Making Arc Flash Clothing Practical for Daily Use

  • Lightweight construction – Allows bending, reaching, and squatting without restriction

  • Breathable fabric – Reduces heat buildup and discomfort

  • Modular configuration – Combine hoods, visors, and sleeves as needed

  • Anti-static performance – Reduces the risk of electrostatic ignition


5. Conclusion

Automation commissioning is a “high-frequency contact, high-risk with low warning” task — danger often comes at the very moment a finger reaches inside a panel.

A compliant arc flash suit is the final barrier between the engineer and the arc.

Whether in smart factories, robotic production lines, or conventional distribution cabinet testing sites, arc flash protection should never be overlooked. Safety is not an optional setting — it is the most critical “system configuration” before every commissioning task begins.
